ASUS

Asus Prime B850-PLUS Wifi Ai PC Ready AMD DDR5 Gaming MotherBoard

Asus Prime B850-PLUS Wifi Ai PC Ready AMD DDR5 Gaming MotherBoard

SKU: 90MB1L80-M0EAY0

Sale Sold out
72.000 KWD
72.000 KWD

Low stock

Add 10.000 KD more to get FREE SHIPPING!
0.000 KD
Key Features
Shipping Info & Warranty
  • Motherboard Series : B Series
  • Socket Type : AMD AM5
  • Form Factor : ATX
  • Memory Type : DDR 5
  • Wi-Fi : Yes

Delivery Charges by Area (Same-Day Delivery)

  1. Al Ahmadi - 4 KWD
  2. Al Asimah - 2 KWD
  3. Al Farwaniyah - 2 KWD
  4. Al Jahra - 5 KWD
  5. Hawalli - 1.5 KWD
  6. Mubarak Al-Kabeer - 3 KWD

Store Pickup: Free

Next-Day Delivery: Free

Orders above 10 KWD: Free Delivery (any area)

Warranty: 1 Year (As per Manufacturer Policy)

Key Features

Shipping Info & Warranty

View the full product details
Description

Asus Prime B850-PLUS WiFi Ai PC Ready AMD DDR5 Gaming MotherBoard

Advanced Performance with AMD B850 Chipset

The ASUS Prime B850-PLUS WiFi motherboard is designed for gamers, creators, and PC enthusiasts who demand stability, speed, and next-gen connectivity. Built around the AMD B850 chipset, it supports Ryzen™ 9000, 8000, and 7000 Series Desktop Processors for superior multitasking and gaming power.

High-Speed DDR5 Memory Support

Equipped with four DIMM slots supporting up to 256GB of DDR5 memory, the board enables blazing-fast speeds up to 8000+MT/s (OC). With support for AMD EXPO™ and ASUS AEMP profiles, users can easily optimize performance for gaming and productivity.

Robust Connectivity and Wireless Freedom

Stay connected with built-in Wi-Fi 6E and Bluetooth® 5.3 support, offering ultra-fast wireless connections and low-latency networking. The board also includes Realtek 2.5Gb Ethernet for wired connections with superior stability and bandwidth.

Comprehensive Cooling and Power Solutions

The motherboard features advanced thermal designs, including a VRM heatsink and flexible M.2 heatsinks, ensuring efficient heat dissipation during demanding workloads or extended gaming sessions. DIGI+ VRM and multiple fan headers provide precise power and cooling control.

Enhanced Expansion and Storage Options

With three M.2 slots and four SATA 6Gb/s ports, users can take advantage of fast storage configurations. PCIe 5.0 and 4.0 slots support the latest GPUs and expansion cards, offering flexibility for future upgrades.

Designed for DIY Builders

ASUS makes building easy with Q-Design features like Q-LED Core indicators, pre-mounted I/O shield, and SafeSlot PCIe protection. The BIOS FlashBack™ button ensures quick and easy updates without requiring a CPU or memory installed.
Specification:
Model No Asus Prime B850-PLUS Wifi Ai PC Ready AMD DDR5 Gaming MotherBoard
Part No 90MB1L80-M0EAY0
Chipset AMD B850 Chipset
Form Factor ATX
Socket Compatibility AMD Socket AM5 for AMD Ryzen™ 9000 & 8000 & 7000 Series Desktop Processors
Wireless & Bluetooth Wi-Fi 6E
2x2 Wi-Fi 6E (802.11ax)
Supports 2.4/5/6GHz frequency band*
Bluetooth® v5.3**
Lighting None
Memory Type 4 x DIMM slots, max. 256GB, DDR5 Supports up to 8000+MT/s (OC) with Ryzen™ 9000 & 8000 & 7000 Series Processors, ECC and Non-ECC Un-buffered DIMM*
Dual channel memory architecture
Supports AMD Extended Profiles for Overclocking (EXPO™)
ASUS Enhanced Memory Profile (AEMP)
Ethernet 1 x Realtek 2.5Gb Ethernet
ASUS LANGuard
Storage Compatibility Supports 3 x M.2 slots and 4 x SATA 6Gb/s ports
AMD Ryzen™ 9000 & 7000 Series Desktop Processors:
M.2_1 slot (Key M), type 2280 (supports PCIe 5.0 x4 mode)
M.2_2 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
AMD Ryzen™ 8000 Series Desktop Processors:
M.2_1 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
M.2_2 slot (Key M), type 2280 (supports PCIe 4.0 x4/x2 mode)*
AMD B850 Chipset:
M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x2 mode)
4 x SATA 6Gb/s ports
* Specifications vary by CPU types.
AMD RAIDXpert2 Technology
Ryzen™ 9000 Series: RAID 0/1/5/10
Ryzen™ 8000 Series: RAID 0/1
Ryzen™ 7000 Series: RAID 0/1/10
Back Panel I/O Ports 1 x USB 10Gbps port (1 x USB Type-C®)
3 x USB 10Gbps ports (3 x Type-A)
2 x USB 5Gbps ports (2 x Type-A)
2 x USB 2.0 ports (2 x Type-A)
1 x DisplayPort
1 x HDMI™ port
1 x Wi-Fi module
1 x Realtek 2.5Gb Ethernet port
3 x Audio jacks
1 x BIOS FlashBack™ button
USB Ports Front (Support) Rear USB (Total 8 ports)
4 x USB 10Gbps port(s) (3 x Type-A + 1 x USB Type-C®)
2 x USB 5Gbps ports (2 x Type-A)
2 x USB 2.0 ports (2 x Type-A)
Front USB (Total 9 ports)
1 x USB 5Gbps connector (supports USB Type-C®)
1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
3 x USB 2.0 headers support 6 additional USB 2.0 ports
* USB Type-C® power delivery output: max. 5V/3A
Expansion Slots AMD Ryzen™ 9000 & 7000 Series:
1 x PCIe 5.0 x16 slot (supports x16 mode)
AMD Ryzen™ 8000 Series:
1 x PCIe 4.0 x16 slot (supports x8/x4 mode)**
AMD B850 Chipset:
1 x PCIe 4.0 x16 slot (support x4 mode)
2 x PCIe 3.0 x16 slots (support x1 mode)***
* Please check PCIe bifurcation table on ASUS support site.
** Specifications vary by CPU types.
*** PCIEX16(G3)_1/2 share bandwidth with SATA6G_1/2 and may disable SATA6G_1/2 when active.
Audio Realtek 7.1 Surround Sound High Definition Audio CODEC*
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- Supports up to 24-Bit/192 kHz playback
Audio Features:
- Audio Shielding
- Premium audio capacitors
- Dedicated audio PCB layers
* A chassis with HD audio module is required for 7.1 Surround Sound output.
Internal I/O Connectors Fan and Cooling Related:
1 x 4-pin CPU Fan header
1 x 4-pin CPU OPT Fan header
1 x 4-pin AIO Pump header
4 x 4-pin Chassis Fan headers
Power Related:
1 x 24-pin Main Power connector
1 x 8-pin +12V CPU Power connector
1 x 4-pin +12V CPU Power connector
Storage Related:
3 x M.2 slots (Key M)
4 x SATA 6Gb/s ports
USB:
1 x USB 5Gbps connector (supports USB Type-C®)
1 x USB 5Gbps header (2 ports)
3 x USB 2.0 headers (6 ports)
Miscellaneous:
3 x Addressable RGB Gen 2 headers
1 x Clear CMOS header
1 x Chassis Intrusion header
1 x COM Port header
1 x Front Panel Audio header
1 x S/PDIF Out header
1 x SPI TPM header (14-1 pin)
1 x 10-1 pin System Panel header
1 x Thunderbolt™ (USB4®) header
Special Features ASUS 5X PROTECTION III:
- DIGI+ VRM, LANGuard, Overvoltage protection, SafeSlot, Stainless-steel back I/O
ASUS Q-Design:
- Q-Antenna, Q-Dashboard, Q-DIMM, Q-LED Core, Q-Slot
ASUS Thermal Solution:
- Flexible M.2 heatsink, VRM heatsink design
ASUS EZ DIY:
- BIOS FlashBack™ button & LED, Pre-mounted I/O shield, SafeSlot
Aura Sync:
- Addressable RGB Gen 2 headers
Package Content Cables:
2 x SATA 6Gb/s cables
Miscellaneous:
1 x ASUS WiFi Q-Antenna
1 x M.2 rubber packages
3 x Screw packages for M.2 SSD
Documentation:
1 x Quick start guide
Product Size ( Dimension ) 12 inch x 9.6 inch (30.5 cm x 24.4 cm)
